Flexibly correspond to both bar and chucker according to the workpieces.
Machine with linear scale
●Reduces influence of thermal displacement by the linear scale, and improves machining accuracy.
●Built-in motor spindle minimizes vibration and improves surface finishes.
●Standard-equipped spindle cooling unit reduces thermal displacement.
●Tooling system selections are available for both bar and chucker to meet a wide variety of workpieces.
●The loader is easy to be installed since height from the spindle center to the top of the cover is 255 mm.
It is also possible to mount through-machine type loader.
